规格型号 | 流量 | 压力Mpa | 吸入真空高度m | 口径mm | 配电机 | ||
m3/h | L/min | 功率 | 型号 | ||||
RCB-1/0.6 | 1 | 16.6 | 0.36 | 3 | 16 | 1.5 | Y90L-4 |
RCB-1/0.8 | 1 | 16.6 | 0.8 | 3 | 16 | 1.5 | Y90L-4 |
RCB-2/0.36 | 2 | 33.3 | 0.36 | 3 | 25 | 1.5 | Y90L-4 |
RCB-2/0.8 | 0.8 | 2.2 | Y100L1-4 | ||||
RCB-3/0.36 | 3 | 50 | 0.36 | 3 | 25 | 1.5 | Y100L-6 |
RCB-3/0.8 | 0.8 | 2.2 | Y112M-6 | ||||
RCB-5/0.36 | 5 | 83.3 | 0.36 | 3 | 40 | 2.2 | Y100L-4 |
RCB-5/0.8 | 0.8 | 4 | Y112M-4 | ||||
RCB-6/0.36 | 6 | 100 | 0.36 | 3 | 40 | 2.2 | Y132M-6 |
RCB-6/0.8 | 0.8 | 3 | 4 | Y132M1-6 | |||
RCB-8/0.36 | 8 | 133 | 0.36 | 3 | 50 | 4 | Y112M-4 |
RCB-8/0.8 | 0.8 | 3 | 5.5 | Y132S-4 | |||
RCB-10/0.36 | 10 | 167 | 0.36 | 3 | 50 | 4 | Y132M-6 |
RCB-10/0.8 | 0.8 | 3 | 5.5 | Y132M2-4 | |||
RCB-12/0.36 | 12 | 200 | 0.36 | 3 | 50 | 4 | Y132M-6 |
RCB-12/0.8 | 0.8 | 3 | 5.5 | Y132M2-6 | |||
RCB-18/0.36 | 18 | 300 | 0.36 | 3 | 70 | 5.5 | Y132M2-6 |
RCB-18/0.8 | 0.8 | 3 | 7.5 | Y160M-6 | |||
RCB-29/0.36 | 29 | 483.3 | 0.36 | 3 | 70 | 7.5 | Y132M-4 |
RCB-29/0.8 | 0.8 | 3 | 11 | Y160M-4 | |||
RCB-32/0.36 | 32 | 534 | 0.36 | 3 | 100 | 11 | Y160L-6 |
RCB-32/0.8 | 0.8 | 3 | 15 | Y180L-6 | |||
RCB-38/0.28 | 38 | 633 | 0.36 | 3 | 100 | 11 | Y160L-6 |
RCB-38/0.36 | 0.8 | 3 | 15 | Y180L-6 | |||
RCB-58/0.28 | 58 | 960 | 0.36 | 3 | 100 | 18.5 | Y180M-4 |
RCB-58/0.36 | 0.8 | 3 | 22 | Y180L-4 | |||
RCB-72/0.28 | 72 | 1200 | 0.28 | 3 | 150 | 37 | Y250S-8 |
RCB-96/0.28 | 96 | 1600 | 0.28 | 3 | 150 | 45 | Y280S-6 |
RCB-110/0.28 | 110 | 1800 | 0.28 | 3 | 200 | 55 | Y315S-8 |
RCB-150/0.28 | 150 | 2500 | 0.28 | 3 | 200 | 75 | Y315S-6 |
RCB-170/0.28 | 228 | 3800 | 0.28 | 3 | 250 | 90 | Y315L-6 |
RCB-230/0.28 | 324 | 5400 | 0.28 | 3 | 250 | 110 | Y315L-6 |
